For model Sports 11 ICF-111L, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / LR14: 3 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9.2 cm = 3.6 inch
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: Sports 11 ICF-111L - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 214 x 178 x 56 mm / 8.4 x 7 x 2.2 inch
Notes A guest, Celia Wilson from Hervey Bay, Australia, sent us a message about the date (year) of the model: "Just to let you know that I bought the black/grey model in late 1972 from a shop in Lincoln, England called C R Spouge and it cost me 32 pounds (which was almost 4 weeks wages!). I still have the radio (minus the shoulder strap) and it is still used every day."

Transistors: 1 circuit intégré, 1 transistor FET - poste étanche au ruissellement - haut parleur traité.
Diode d'accord electroluminescente intégrée à l'aiguille du cadran - pile: LR14.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Price in first year of sale 32.00 £
Source of data - - Data from my own collection

Model page created by Jean Claude Pigeon † 2008. See "Data change" for further contributors.
