Powered Stereo Speaker System SRF-80W

Powered Stereo Speaker System SRF-80W; Sony Corporation; (ID = 2501062) Speaker-P Powered Stereo Speaker System SRF-80W; Sony Corporation; (ID = 2501063) Speaker-P
Powered Stereo Speaker System SRF-80W; Sony Corporation; (ID = 2501141) Speaker-P Powered Stereo Speaker System SRF-80W; Sony Corporation; (ID = 616382) Speaker-P
Use red slider bar for more.
Powered Stereo Speaker System SRF-80W; Sony Corporation; (ID = 2501062) Speaker-P
Sony Corporation;: Powered Stereo Speaker System SRF-80W [Speaker-P] ID = 2501062 1200x736
Select picture or schematic to display from thumbnails on the right and click for download.
For model Powered Stereo Speaker System SRF-80W, Sony Corporation; Tokyo:
Funkschau 3/1981, S. 81

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1981 Category: Loudspeaker, headphone or earphone
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Batteries / addl. power jack / C: 4 x 1.5 / DC 6 Volt
Loudspeaker 2 Loudspeakers / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: Powered Stereo Speaker System SRF-80W - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 321 x 131 x 49 mm / 12.6 x 5.2 x 1.9 inch
Notes

Sony SRF-80W consists of two elements: the speaker/amplifier described here and an FM/AM receiver with the same model number that is slotted into the bay.

Telescopic antenna.
Auxiliary stereo input jack.
Optional: Power Supply AC-130W (USA), 12V Car Battery Cord DCC-127A

Instead of the tuner, Stereo Cassette-Corder TCS-300 can be used with the speaker system.

Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Mentioned in Funkschau (3/1981, S. 81/ Beschreibung)
Literature/Schematics (2) -- Original-techn. papers.

Model page created by a member from A. See "Data change" for further contributors.
