Stereo Cassette Player MTL-10
Sony Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sony Corporation; Tokyo
- Year
- 1983
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 292929
Frontansicht Servicemanual
technische Daten aus Servicemanual
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player; Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / see remarks Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Cassette Player MTL-10 - Sony Corporation; Tokyo
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 355 x 105 x 208 mm / 14 x 4.1 x 8.2 inch
- Notes
-
Cassette player with magazine for up to 10 cassettes. Playback with programmable memory. Auto-reverse with ror-bilateral head. Blank skip function, AMS (Automatic Music Sensor).
Power requirements:
- USA, Canada: 60 Hz, 120 V
- Asia, Europe, Pacific: 50/60 Hz, 220 V
- UK: 50/60 Hz, 240 V
- Europe: 50/60 Hz, 110/120/220/240 V
- Net weight (2.2 lb = 1 kg)
- 5.7 kg / 12 lb 8.9 oz (12.555 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Peter Böhm. See "Data change" for further contributors.
