• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1969–1972

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 157077

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• 2SC631 2SC631 2SC633 2SC633 2SC633 2SC633 2SC634 2SC634 2SB495 2SB495 10D-5 1T22 10D-2 10D-2 10D-2 10D-2

• Main principle
• Audio-Amplification

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110; 120; 240 / C: 4 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: TC-80 - Sony Corporation; Tokyo

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 225 x 62 x 182 mm / 8.9 x 2.4 x 7.2 inch

• Notes

• Integriertes Elektret-Mikrofon.

• Net weight (2.2 lb = 1 kg)
• 2.1 kg / 4 lb 10 oz (4.626 lb)

• Mentioned in
• -- Schematic

• Literature/Schematics (1)
• Selezione Radio-TV Dezember 1972

• Literature/Schematics (2)
• Praktiker Nr. 5/1970, Seite 28

• Literature/Schematics (3)
• Funk-Technik (FT) (23/1969, S. 898 / Neuvorstellung)
