For model TFM8100WA, Sony Corporation; Tokyo:
Thanks for Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 16:
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Batteries / addl. power jack / 3 × 1,5 ; 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9.2 cm = 3.6 inch
Power out 1.1 W (unknown quality)
from Radiomuseum.org Model: TFM8100WA - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 214 x 178 x 56 mm / 8.4 x 7 x 2.2 inch
Notes MW: 530-1605 kHz,
FM: 87,5-108 MHz,
Weather: 161-163,3 MHz.
Ext. Power Jack: DC 4,5 V.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Literature/Schematics (1) -- Original prospect or advert

Model page created by Salvador Galan-Ocaña. See "Data change" for further contributors.
