TFM-951L

TFM-951L; Sony Corporation; (ID = 1826211) Radio TFM-951L; Sony Corporation; (ID = 1826213) Radio
TFM-951L; Sony Corporation; (ID = 680633) Radio TFM-951L; Sony Corporation; (ID = 680634) Radio
TFM-951L; Sony Corporation; (ID = 680635) Radio TFM-951L; Sony Corporation; (ID = 680705) Radio
TFM-951L; Sony Corporation; (ID = 1839042) Radio
Use red slider bar for more.
TFM-951L; Sony Corporation; (ID = 1826211) Radio
Sony Corporation;: TFM-951L [Radio] ID = 1826211 1400x1268
Select picture or schematic to display from thumbnails on the right and click for download.
For model TFM-951L, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9:
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: TFM-951L - Sony Corporation; Tokyo
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 250 x 170 x 85 mm / 9.8 x 6.7 x 3.3 inch
Notes FM 85-108 Mc. MW 530-1605 kc. LW 150-350 kc.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)

Model page created by Salvador Galan-Ocaña. See "Data change" for further contributors.
