Videocorder TCV-2020

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1965
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 142298

 Technical Specifications

  • Number of Tubes
  • 1
  • Valves / Tubes
  • Number of Transistors
  • 76
  • Semiconductors
  • Wave bands
  • - without
  • Details
  • Video-Taperecorder/-Player
  • Power type and voltage
  • Alternating Current supply (AC) / 117 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 0.3 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Videocorder TCV-2020 - Sony Corporation; Tokyo
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 28.38 x 16.75 x 11.25 inch / 721 x 425 x 286 mm
  • Notes

  • Receive, record and playback video and audio signals of U.S. TV Standards in black and white.
    Tape Sony V-Series, width 0,5", spool diameter 7" maximum, 2,63x4" loudspeaker 40 ohms, VHF channels 2-13, UHF-channels 14-83. Built in Videocorder-Screen with 9" picture tube, 90 degree deflection, aluminized screen. Can be used as a normal TV Receiver.
    Camera Input for Sony CVC-2000.
    Clock-Timer built in to record programs in the owner's absence.
    76 transistors, 38 diodes, 4 thermistors and 1 Selenium rectifier. Walnut cabinet.

  • Net weight (2.2 lb = 1 kg)
  • 35 kg / 77 lb 1.5 oz (77.093 lb)
  • Price in first year of sale
  • 1,250.00 $
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
