Watchman FD-10A

Watchman FD-10A; Sony Corporation; (ID = 1922918) Television Watchman FD-10A; Sony Corporation; (ID = 1788430) Television
Watchman FD-10A; Sony Corporation; (ID = 1365716) Television Watchman FD-10A; Sony Corporation; (ID = 1070201) Television
Watchman FD-10A; Sony Corporation; (ID = 1070202) Television Watchman FD-10A; Sony Corporation; (ID = 1070203) Television
Watchman FD-10A; Sony Corporation; (ID = 1070204) Television Watchman FD-10A; Sony Corporation; (ID = 1070205) Television
Watchman FD-10A; Sony Corporation; (ID = 1365717) Television Watchman FD-10A; Sony Corporation; (ID = 1369583) Television
Use red slider bar for more.
Watchman FD-10A; Sony Corporation; (ID = 1922918) Television
Sony Corporation;: Watchman FD-10A [Television] ID = 1922918 536x900
Select picture or schematic to display from thumbnails on the right and click for download.
For model Watchman FD-10A, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1986/1987 Category: Television Receiver (TV) or Monitor
Valves / Tubes 1:
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage and/or dry batteries / 4 x 1,2; 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 1.13 inch = 2.9 cm
Power out
from Radiomuseum.org Model: Watchman FD-10A - Sony Corporation; Tokyo
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Notes Sony FD-10A Watchman; 2"/5 cm b/w special CRT, US standard VHF & UHF tuner with yellow scale pointer, audio only operation, built-in telescopic antenna, earphone jack, ~410 g, red color, optional screen magnifier type VCV-2, 1.6 watts power consumption with operation time 5/35 hours. Optional accu recharger type BC-3K4.
Source of data -- Original prospect or advert

Model page created by a member from A. See "Data change" for further contributors.
