For model Sparton 1007 Ch= 8-57, Sparks-Withington Co., (Sparton); Jackson, Michigan:
Not original speaker grill cloth. I have evidence the original cloth was burgundy in color.

Country:  United States of America (USA)
Manufacturer / Brand:  Sparks-Withington Co., (Sparton); Jackson, Michigan
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6BA6 6BE6 7A7 7A7 7C7 6S8GT 7B5 5Y3GT
Main principle Superhet with RF-stage; ZF/IF 456/10700 kHz; 2 AF stage(s)
Tuned circuits 9 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9.5 inch = 24.1 cm
Power out
from Radiomuseum.org Model: Sparton 1007 Ch= 8-57 - Sparks-Withington Co., Sparton
Material Wooden case
Shape Console with any shape - in general
Notes The Sparks Model Sparton 1007 is an AC Operated 8 Tube Combination Phono-Radio, AM-FM Superheterodyne Receiver with Loop Antenna.
Price in first year of sale 229.95 $
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 18 = 1949 and before
Mentioned in Rider's 18-3 to 18-10, 19-7
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 29, Folder 4719-25)
Literature/Schematics (2) Radio Retailing (Radio & Television R.) (July 1947 page 14. August 1947 page 28.)
