Tel-Ohmike Capacitor Analyzer TO-5
Sprague Electric Company; North Adams, MA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sprague Electric Company; North Adams, MA
- Year
- 1958
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 162692
Meter movment not original.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Tel-Ohmike Capacitor Analyzer TO-5 - Sprague Electric Company;
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 14 x 8 x 6 inch / 356 x 203 x 152 mm
- Notes
- Multi purpose instrument for checking and measuring: capacitance, power factor, and insulation resistance of paper, mica and ceramic capacitors. Measurement of leakage current at rated voltage for electrolytic capacitors in range 50-600V adjustable. Insulation resistance is measured directly in range from 100 to 20000 megaohms. Automatic discharge of capacitors after measurement is also present. Additional feature is turns and impendance ratio bridge for laminated output, interstage, power and line transformers in two ranges: 1:1 to 100:1 and 100:1 to 10000:1. TO-5 was also available in TO-5R, which is 19" rack mountable and TO-5X which is export version, 115/230V switchable.
- Net weight (2.2 lb = 1 kg)
- 6 kg / 13 lb 3.5 oz (13.216 lb)
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by Sinisa Trlin. See "Data change" for further contributors.
