Thermo Power Meter TPM4

Thermo Power Meter TPM4; SSB-Electronic GmbH; (ID = 497745) Equipment

Thermo Power Meter TPM4; SSB-Electronic GmbH; (ID = 497746) Equipment

Thermo Power Meter TPM4; SSB-Electronic GmbH; (ID = 497747) Equipment

Thermo Power Meter TPM4; SSB-Electronic GmbH; (ID = 497748) Equipment

Thermo Power Meter TPM4; SSB-Electronic GmbH; (ID = 497749) Equipment
Thermo Power Meter TPM4; SSB-Electronic GmbH; (ID = 497482) Equipment Thermo Power Meter TPM4; SSB-Electronic GmbH; (ID = 497481) Equipment
Use red slider bar for more.
Thermo Power Meter TPM4; SSB-Electronic GmbH; (ID = 497482) Equipment
SSB-Electronic GmbH;: Thermo Power Meter TPM4 [Equipment] ID = 497482 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Thermo Power Meter TPM4, SSB-Electronic GmbH; Iserlohn

Country:  Germany
Manufacturer / Brand:  SSB-Electronic GmbH; Iserlohn
Year: 1985 ? Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Dry Batteries / 6 x 1,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Thermo Power Meter TPM4 - SSB-Electronic GmbH; Iserlohn
Material Metal case
Dimensions (WHD) 200 x 125 x 150 mm / 7.9 x 4.9 x 5.9 inch
Notes Analoges, thermisches HF-Effektivwert-Leistungsmessgerät für Leistungen an einer 50-Ohm-Senke in 6 Messbereichen, beginnend mit 0-0,3 mW bis 0-100 mW. Der Frequenzbereich beginnt mit Gleichstrom "0 Hz" und reicht hinauf bis 11 GHz. Das Gerät enthält keine Röhren oder Transistoren sondern 4 ICs: 7805, µA741, OP07CN, µA741.
Source of data - - Data from my own collection

Model page created by Dieter Barkawitz. See "Data change" for further contributors.



All listed radios etc. from SSB-Electronic GmbH; Iserlohn
Here you find 2 models, 2 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
