• Country
• Hungary

• Manufacturer / Brand
• Standard; Budapest

• Year
• 1943 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 234742

• Number of Tubes
• 5

• Valves / Tubes
• ECH3 EF9 EBL1 EZ3 EM4

• Main principle
• Superheterodyne (common); ZF/IF 127 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-250 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Szuper 41 Ch= 3033 - Standard; Budapest

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 560 x 380 x 290 mm / 22 x 15 x 11.4 inch

• Notes

• Produktion during World War 2. Box: Super 41, Chassis: Hármasszuper 3033

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Mentioned in
• Rádiókészülékek Kapcsolásai 1936-56

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.

• Other Models

• Here you find 156 models, 147 with images and 88 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
