• Year
  • 1932–1934
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 150523

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • TRF (Tuned-Radio-Frequency but use of regeneration unknown)
  • Tuned circuits
  • 5 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Szuper X - Standard; Budapest
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Price in first year of sale
  • 295.00 Pengö
  • Literature/Schematics (1)
  • The History of Hungarian Radio Broadcasting and a Catalogue of Radio Receivers
