• Country
• Australia

• Manufacturer / Brand
• Standard Telephones and Cables Pty, Ltd (STC), Sydney

• Year
• 1935

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 335144

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 58 2A7 58 58 2B7 2A5 80

• Main principle
• Superhet with RF-stage; ZF/IF 450 kHz; 2 AF stage(s)

• Tuned circuits
• 9 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 776 CH=77 - Standard Telephones and Cables

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 440 x 560 x 315 mm / 17.3 x 22 x 12.4 inch

• Notes

• 7-valve superhet with RF stage

  Was also available in Console Model 778.

  Also sold in New Zealand.

• Mentioned in
• -- Original prospect or advert (Auckland Star 15 June 1935 Page 21)

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
