Absorptionsfrequenzmesser FM1

Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 879125) Equipment
Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 1704344) Equipment Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 1476844) Equipment
Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 159883) Equipment Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 159885) Equipment
Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 159886) Equipment Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 159887) Equipment
Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 657555) Equipment Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 657556) Equipment
Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 657557) Equipment Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 657558) Equipment
Use red slider bar for more.
Absorptionsfrequenzmesser FM1; Steeg, Dr., & Reuter (ID = 1704344) Equipment
Steeg, Dr., & Reuter: Absorptionsfrequenzmesser FM1 [Equipment] ID = 1704344 930x1221
Select picture or schematic to display from thumbnails on the right and click for download.
For model Absorptionsfrequenzmesser FM1, Steeg, Dr., & Reuter, Bad Homburg v.d.H.:
This is a similar instrument made by Rohde & Schwartz. Under the dial I found the Steege and Reuter logo.

Country:  Germany
Manufacturer / Brand:  Steeg, Dr., & Reuter, Bad Homburg v.d.H.
Year: 1943 ? Category: Service- or Lab Equipment
Main principle Crystal or Solid State Detector
Details
Power type and voltage No Power needed
Loudspeaker
Power out
from Radiomuseum.org Model: Absorptionsfrequenzmesser FM1 - Steeg, Dr., & Reuter, Bad
Material Wooden case
Dimensions (WHD) 190 x 250 x 105 mm / 7.5 x 9.8 x 4.1 inch
Notes Der Frequenzmesser arbeitet nach dem Resonanzverfahren im Frequenzbereich von 150 kHz bis 60 MHz. Der Meßbereich ist durch fünf stufenweise umschaltbare Induktivitäten unterteilt. Zur Resonanzanzeige dient eine Diodenschaltung, wobei zur Gleichrichtung ein Detektor verwendet wird. Als Indikator arbeitet ein Drehspulinstrument. Das Gerät benötigt keine Stromversorgung.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Source of data - - Data from my own collection

Model page created by Giovanni Cucuzzella. See "Data change" for further contributors.



All listed radios etc. from Steeg, Dr., & Reuter, Bad Homburg v.d.H.
Here you find 15 models, 9 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
