• Country
• United States of America (USA)

• Manufacturer / Brand
• Steelman Phono & Radio Co.; Mount Vernon (NY)

• Year
• 1953 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 196112

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AT6 50C5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Wave bands
• Broadcast only (MW).

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 60Hz, 117V=110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: 3AR1 - Steelman Phono & Radio Co.;

• Shape
• Tablemodel, with any shape - general.

• Notes

• Steelman model 3AR1 is an AC operated radio-phono combination superheterodyne receiver with 3 speed automatic record changer.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 217, folder 17, dated 10-53)

• Author
• Model page created by Richard Watts. See "Data change" for further contributors.
