Stern-Picknick R130-10 KML; Stern-Radio Berlin, (ID = 364269) Radio
Stern-Radio Berlin,: Stern-Picknick R130-10 KML [Radio] ID = 364269 933x682
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stern-Picknick R130-10 KML, Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG
alternative name

Phonetika Radio Berlin, VEB; Berlin, (Ostd.)
Year: 1969 Category: Broadcast Receiver - or past WW2 Tuner
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries / 7,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: Stern-Picknick R130-10 KML - Stern-Radio Berlin, VEB, RFT,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 272 x 168 x 79 mm / 10.7 x 6.6 x 3.1 inch
Notes 8 Ge Transistoren 3 Ge Dioden Anschlüsse für Autoantenne und Ohrhörer Plastgehäuse Klangtaste, Ovallautsprecher LP553 mit Z = 8 Ohm, Leistung 1,5 Watt. Eisenlose Endstufe.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 315.00 DM
Collectors' prices
Source of data -- Collector info (Sammler) / Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original-techn. papers.

Model page created by Bernd Freytag. See "Data change" for further contributors.
