Stern-Berolina T140; Stern-Radio Berlin, (ID = 65145) Radio
Stern-Radio Berlin,: Stern-Berolina T140 [Radio] ID = 65145 917x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stern-Berolina T140, Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG
alternative name

Phonetika Radio Berlin, VEB; Berlin, (Ostd.)
Year: 1971/1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: GF132 GF181 GF130 GF130 GF130 GC117 SC206 GC116 GC116 GC507 101NU71 GA113 GA113 GA101
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 5 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 cm = 2.6 inch
Power out 0.17 W (unknown quality)
from Radiomuseum.org Model: Stern-Berolina T140 - Stern-Radio Berlin, VEB, RFT,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 190 x 107 x 44 mm / 7.5 x 4.2 x 1.7 inch
Notes

Erster Taschenempfänger mit UKW in der DDR. Kurzwelle nur 49 m- Band, klappbarer Griff. Lautsprecher LP112 mit Z = 15 Ω, 0,25W. Eisenlose Endstufe, das komplementäre Paar kommt von Tesla, CSSR. Später hergestellte Geräte können auch im HF-Teil Importtransistoren enthalten.

Produktion 1972 in Berlin beendet, verlagert nach Antennenwerke Bad Blankenburg, Überarbeitung des Modells und als Berolina de luxe gefertigt.

Net weight (2.2 lb = 1 kg) 0.6 kg / 1 lb 5.1 oz (1.322 lb)
Price in first year of sale 340.00 DM
Collectors' prices
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Funkverlag Hein, Service-DVD
Literature/Schematics (1) Funkamateur H.6/1972, Radio Fernsehen Elektronik H.2 und H.9/1972.

Model page created by Iven Müller. See "Data change" for further contributors.



All listed radios etc. from Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG
Here you find 233 models, 214 with images and 170 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Stern-Radio Berlin,: Stern-Berolina T140
Threads: 1 | Posts: 1
Hits: 1668     Replies: 0
stern-berl: T140; Stern-Berolina
Egon Strampe
07.May.11
  1

AM geht nicht und UKW nur leise: An Emitter und an der Basis von T4 liegt eine zu hohe negative Spannung.  C 36 hatte Schluß.
