Stern Dynamic 2020

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 105351) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 105467) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 412464) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 412465) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 528557) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 1267272) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 1462401) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 2273008) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 2558431) Radio

Stern Dynamic 2020; Stern-Radio Berlin, (ID = 2558432) Radio
Stern Dynamic 2020; Stern-Radio Berlin, (ID = 75777) Radio Stern Dynamic 2020; Stern-Radio Berlin, (ID = 75778) Radio
Stern Dynamic 2020; Stern-Radio Berlin, (ID = 592509) Radio Stern Dynamic 2020; Stern-Radio Berlin, (ID = 427887) Radio
Stern Dynamic 2020; Stern-Radio Berlin, (ID = 592506) Radio Stern Dynamic 2020; Stern-Radio Berlin, (ID = 592507) Radio
Stern Dynamic 2020; Stern-Radio Berlin, (ID = 592508) Radio Stern Dynamic 2020; Stern-Radio Berlin, (ID = 836508) Radio
Stern Dynamic 2020; Stern-Radio Berlin, (ID = 836509) Radio Stern Dynamic 2020; Stern-Radio Berlin, (ID = 836510) Radio
Use red slider bar for more.
Stern Dynamic 2020; Stern-Radio Berlin, (ID = 75777) Radio
Stern-Radio Berlin,: Stern Dynamic 2020 [Radio] ID = 75777 864x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stern Dynamic 2020, Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG
alternative name

Phonetika Radio Berlin, VEB; Berlin, (Ostd.)
Year: 1974/1975 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: SF225 SF225 SF225 SC207 SC206 AC188 AC187
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Stern Dynamic 2020 - Stern-Radio Berlin, VEB, RFT,
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 275 x 175 x 82 mm / 10.8 x 6.9 x 3.2 inch
Notes Der Koffersuper Stern Dynamic 2020 (R200-20) hat einen Kurzwellenbereich von 5,9 bis 6,2 MHz. Der eisenlos komplementär aufgebaute NF- Verstärker liefert eine Leistung von 1 Watt und hat eine Klangblende. Anschlußbuchsen für TA/ TB, Netz, einen Außenlautsprecher und für eine auf alle Wellenbereiche wirkende Autoantenne sind eingebaut. Die AFC für UKW ist nicht abschaltbar.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 525.00 DM
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) Service-DVD Funkverlag B. Hein (Zeitschrift Radio Fernsehen Elektronik Jahrgang 1975 Heft 8 Seite 260)
Literature/Schematics (2) Das Kofferradio in der DDR (B.3 Geschichte der Rundfunkind. der DDR)

Model page created by Michael Seiffert. See "Data change" for further contributors.
