Stern Touring A130-20

Stern Touring A130-20; Stern-Radio Berlin, (ID = 108094) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799692) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799693) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799698) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799699) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799700) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799701) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799702) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799703) Car Radio

Stern Touring A130-20; Stern-Radio Berlin, (ID = 799704) Car Radio
Stern Touring A130-20; Stern-Radio Berlin, (ID = 849552) Car Radio Stern Touring A130-20; Stern-Radio Berlin, (ID = 240604) Car Radio
Stern Touring A130-20; Stern-Radio Berlin, (ID = 240607) Car Radio Stern Touring A130-20; Stern-Radio Berlin, (ID = 424190) Car Radio
Stern Touring A130-20; Stern-Radio Berlin, (ID = 424191) Car Radio Stern Touring A130-20; Stern-Radio Berlin, (ID = 424192) Car Radio
Use red slider bar for more.
Stern Touring A130-20; Stern-Radio Berlin, (ID = 849552) Car Radio
Stern-Radio Berlin,: Stern Touring A130-20 [Car Radio] ID = 849552 800x537
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stern Touring A130-20, Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG
alternative name

Phonetika Radio Berlin, VEB; Berlin, (Ostd.)
Year: 1971 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 18:
Main principle Super-Heterodyne (Super in general); ZF/IF 455/ 10700 kHz
Tuned circuits 9 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Stern Touring A130-20 - Stern-Radio Berlin, VEB, RFT,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 185 x 50 x 133 mm / 7.3 x 2 x 5.2 inch
Notes Empfänger mit zusätzlicher Fernbedienung für Sendersuchlauf (Kapazitätsdioden) und Lautstärke. Grundgerät mit separatem 4-W-NF-Verstärker mit Steckanschluss beim Fahrer, Fernbedienungsteil hinten im Fahrzeug mit Messwerk zur Frequenzanzeige, 0,8 kg.
Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Price in first year of sale 850.00 DM
Collectors' prices
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original prospect or advert (Funkverlag Hein, Service-DVD)
Literature/Schematics (1) rfe Jahrgang 1973, Heft 8 Seite 258

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
