Colorlux 3011

Colorlux 3011; Stern-Radio Staßfurt (ID = 1254921) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1254925) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1254928) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1254935) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1254936) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1254939) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1254940) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1254945) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1255072) Television

Colorlux 3011; Stern-Radio Staßfurt (ID = 1255073) Television
Colorlux 3011; Stern-Radio Staßfurt (ID = 1254081) Television
Use red slider bar for more.
Colorlux 3011; Stern-Radio Staßfurt (ID = 1254081) Television
Stern-Radio Staßfurt: Colorlux 3011 [Television] ID = 1254081 915x644
Select picture or schematic to display from thumbnails on the right and click for download.
For model Colorlux 3011, Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...:
Titelbild aus der Serviceanleitung.

Country:  Germany
Manufacturer / Brand:  Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...
alternative name

Fernsehgerätewerk Staßfurt
Year: 1980 Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: A67-701X
Semiconductors (the count is only for transistors) 80:
Main principle Superheterodyne (common); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Colorlux 3011 - Stern-Radio Staßfurt, VEB, RFT
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 800 x 540 x 450 mm / 31.5 x 21.3 x 17.7 inch
Notes Das Secam- Gerät Colorlux 3011 basiert auf dem Chassis Colortron 3000, ist aber mit der IR- Fernbedienung Selectron 01 fernbedienbar. Das Gerät hat 8 Programmspeicherplätze, eine Kopfhörerbuchse und einen Magnetbandanschluß. Eine Siebensegment- Anzeige zeigt den gewählten Programmplatz. Vorstellung des Gerätes auf der Leipziger Herbstmesse 1980.
Net weight (2.2 lb = 1 kg) 40 kg / 88 lb 1.7 oz (88.106 lb)
Source of data -- Schematic
Literature/Schematics (1) Service-DVD Funkverlag B. Hein
