9152-B

9152-B ; Stewart Warner Corp. (ID = 66179) Radio

9152-B ; Stewart Warner Corp. (ID = 66180) Radio

9152-B ; Stewart Warner Corp. (ID = 114949) Radio

9152-B ; Stewart Warner Corp. (ID = 982745) Radio

9152-B ; Stewart Warner Corp. (ID = 982746) Radio

9152-B ; Stewart Warner Corp. (ID = 982747) Radio

9152-B ; Stewart Warner Corp. (ID = 982748) Radio
9152-B ; Stewart Warner Corp. (ID = 246151) Radio 9152-B ; Stewart Warner Corp. (ID = 246152) Radio
9152-B ; Stewart Warner Corp. (ID = 246153) Radio 9152-B ; Stewart Warner Corp. (ID = 1129049) Radio
9152-B ; Stewart Warner Corp. (ID = 1521650) Radio
Use red slider bar for more.
9152-B ; Stewart Warner Corp. (ID = 246151) Radio
Stewart Warner Corp.: 9152-B [Radio] ID = 246151 858x650
Select picture or schematic to display from thumbnails on the right and click for download.
For model 9152-B, Stewart Warner Corp.; Chicago (IL):
Ebay Nr. 170017311937 Bild bearbeitet.

Country:  United States of America (USA)
Manufacturer / Brand:  Stewart Warner Corp.; Chicago (IL)
Brand

Ferrodyne
Year: 1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AT6 50B5 35W4
schematic requested
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: 9152-B - Stewart Warner Corp.; Chicago
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Collectors' prices
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Rider's Perpetual, Volume 21, Copyright 1950
Literature/Schematics (1) Beitman Radio Diagrams, Vol. 10, 1950
