For model AM/FM Tuner SR-402, Stromberg-Carlson Co. ; Rochester (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  Stromberg-Carlson Co. ; Rochester (NY)
Brand

Te-Lek-Tor-Et
Year: 1958 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 14: 6BQ7A 6BQ7A 6AU6 6BA6 6BE6 6BA6 6BA6 6BA6 6AL5 6U5 6AL5 6AL5 6C4 6X4
Main principle Superhet with RF-stage; ZF/IF 455/10700 kHz; 1 AF stage(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 105 -125 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: AM/FM Tuner SR-402 - Stromberg-Carlson Co. ;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 12 x 5 x 9 inch / 305 x 127 x 229 mm
Notes

Stromberg-Carlson model SR-402 is an AC operated FM-AM tuner.
FM frequency response 20 - 20,000 Hz at less than 1% distortion. Temperature compensated oscillator circuits prevent drift on AM and FM. FM sensitivity 1.5 uv for 20 dB quieting. Two position bandwidth control on AM. Automatic Frequency Control (AFC) on FM.

Source of data - - Manufacturers Literature
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 395 Folder 17 dated 4-58)

Model page created by Mark Donen. See "Data change" for further contributors.
