Amplifier AU-42

Amplifier AU-42; Stromberg-Carlson Co (ID = 2482481) Ampl/Mixer
Amplifier AU-42; Stromberg-Carlson Co (ID = 1794338) Ampl/Mixer Amplifier AU-42; Stromberg-Carlson Co (ID = 1794655) Ampl/Mixer
Amplifier AU-42; Stromberg-Carlson Co (ID = 1795227) Ampl/Mixer Amplifier AU-42; Stromberg-Carlson Co (ID = 1795228) Ampl/Mixer
Amplifier AU-42; Stromberg-Carlson Co (ID = 1795229) Ampl/Mixer Amplifier AU-42; Stromberg-Carlson Co (ID = 1795230) Ampl/Mixer
Amplifier AU-42; Stromberg-Carlson Co (ID = 1795232) Ampl/Mixer
Use red slider bar for more.
Amplifier AU-42; Stromberg-Carlson Co (ID = 1794338) Ampl/Mixer
Stromberg-Carlson Co: Amplifier AU-42 [Ampl/Mixer] ID = 1794338 1120x960
Select picture or schematic to display from thumbnails on the right and click for download.
For model Amplifier AU-42, Stromberg-Carlson Co. ; Rochester (NY):
aus ebay, #121566313837, Verkäufer hmb3823

Country:  United States of America (USA)
Manufacturer / Brand:  Stromberg-Carlson Co. ; Rochester (NY)
Brand

Te-Lek-Tor-Et
Year: 1950 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 6: 6SF5 6J5 or 6C5 6SC7 6L6G 6L6G 5Y3GT/G
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 50-60 cycles, 105-125 Volt
Loudspeaker - This model requires external speaker(s).
Power out 15 W (unknown quality)
from Radiomuseum.org Model: Amplifier AU-42 - Stromberg-Carlson Co. ;
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 13.5 x 10.25 x 7.5 inch / 343 x 260 x 191 mm
Notes

PA amplifier; inputs: Microphone + Phonograph.

Net weight (2.2 lb = 1 kg) 26 lb (26 lb 0 oz) / 11.804 kg
Mentioned in -- Schematic

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
