Custom Four Hundred AP-428

Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 2413141) Ampl/Mixer

Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 2413142) Ampl/Mixer

Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 2413143) Ampl/Mixer

Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 2413144) Ampl/Mixer

Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 2413145) Ampl/Mixer

Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 2413146) Ampl/Mixer
Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 489446) Ampl/Mixer Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 489447) Ampl/Mixer
Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 489448) Ampl/Mixer Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 489449) Ampl/Mixer
Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 489450) Ampl/Mixer Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 2413140) Ampl/Mixer
Use red slider bar for more.
Custom Four Hundred AP-428; Stromberg-Carlson Co (ID = 489446) Ampl/Mixer
Stromberg-Carlson Co: Custom Four Hundred AP-428 [Ampl/Mixer] ID = 489446 872x672
Select picture or schematic to display from thumbnails on the right and click for download.
For model Custom Four Hundred AP-428, Stromberg-Carlson Co. ; Rochester (NY):
aus ebay, Verkäufer urbanradio

Country:  United States of America (USA)
Manufacturer / Brand:  Stromberg-Carlson Co. ; Rochester (NY)
Brand

Te-Lek-Tor-Et
Year: 1957 ? Category: Audio Amplifier or -mixer
Valves / Tubes 6: 12AU7 12AU7 6L6G 6L6G 5Y3GT 6X4
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker - This model requires external speaker(s).
Power out 25 W (unknown quality)
from Radiomuseum.org Model: Custom Four Hundred AP-428 - Stromberg-Carlson Co. ;
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 16 x 8.25 x 7 inch / 406 x 210 x 178 mm
Notes

Stromberg-Carlson model AP428 is an AC operated audio amplifier.

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 365 Folder 14 dated 7-57)

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
