For model EP-2, Stromberg-Carlson Co. ; Rochester (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  Stromberg-Carlson Co. ; Rochester (NY)
Brand

Te-Lek-Tor-Et
Year: 1954 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1R5 1U4 1U5 3V4
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / 117; 3 & 75 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out
from Radiomuseum.org Model: EP-2 - Stromberg-Carlson Co. ;
Material Moulded (Bakelite or Plastics)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 255 x 172 x 72 mm / 10 x 6.8 x 2.8 inch
Notes Stromberg-Carlson EP-2 radio with folding handle in the middle of top unit. Color known so far: Orange. For battery use 2 x 1,5 V type 21R and 1 x 75 V type P45 required.
Net weight (2.2 lb = 1 kg) 1.650 kg / 3 lb 10.1 oz (3.634 lb)
Source of data Beitman Radio Diagrams, Vol. 15, 1955

Model page created by Egon Penker. See "Data change" for further contributors.
