• Country
• Germany

• Manufacturer / Brand
• Studer GmbH, Willi (ReVox); Löffingen

• Year
• 1970/1971

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 28283

• • Brand: ReVox (brand)

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 30

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-260 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Revox A50 [1970] - Studer GmbH, Willi ReVox;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 415 x 160 x 245 mm / 16.3 x 6.3 x 9.6 inch

• Notes
• Stereo-Vollverstärker, 2× 40 W (Sinus).

• Net weight (2.2 lb = 1 kg)
• 8.2 kg / 18 lb 1 oz (18.062 lb)

• Price in first year of sale
• 1,165.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1970/1971 / Radiokatalog Band 2, Ernst Erb
