Revox A722

Revox A722; Studer GmbH, Willi (ID = 318609) Ampl/Mixer

Revox A722; Studer GmbH, Willi (ID = 318610) Ampl/Mixer

Revox A722; Studer GmbH, Willi (ID = 318611) Ampl/Mixer

Revox A722; Studer GmbH, Willi (ID = 318612) Ampl/Mixer

Revox A722; Studer GmbH, Willi (ID = 318608) Ampl/Mixer
Revox A722; Studer GmbH, Willi (ID = 84003) Ampl/Mixer Revox A722; Studer GmbH, Willi (ID = 637114) Ampl/Mixer
Revox A722; Studer GmbH, Willi (ID = 84005) Ampl/Mixer Revox A722; Studer GmbH, Willi (ID = 84004) Ampl/Mixer
Revox A722; Studer GmbH, Willi (ID = 325729) Ampl/Mixer Revox A722; Studer GmbH, Willi (ID = 489987) Ampl/Mixer
Revox A722; Studer GmbH, Willi (ID = 565444) Ampl/Mixer Revox A722; Studer GmbH, Willi (ID = 637115) Ampl/Mixer
Revox A722; Studer GmbH, Willi (ID = 637116) Ampl/Mixer Revox A722; Studer GmbH, Willi (ID = 637117) Ampl/Mixer
Use red slider bar for more.
Revox A722; Studer GmbH, Willi (ID = 84003) Ampl/Mixer
Studer GmbH, Willi: Revox A722 [Ampl/Mixer] ID = 84003 791x523
Select picture or schematic to display from thumbnails on the right and click for download.
For model Revox A722, Studer GmbH, Willi (ReVox); Löffingen

Country:  Germany
Manufacturer / Brand:  Studer GmbH, Willi (ReVox); Löffingen
Brand

ReVox (brand)
Year: 1973–1978 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 45:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 150; 220; 250 Volt
Loudspeaker - This model requires external speaker(s).
Power out 120 W (180 W max.)
from Radiomuseum.org Model: Revox A722 - Studer GmbH, Willi ReVox;
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 240 x 151 x 355 mm / 9.4 x 5.9 x 14 inch
Notes

Revox A722

Stereo-Endstufe passend zum A720, Ferneinschaltung durch A720 möglich. 2 Lautsprecherausgänge schaltbar (A/B), 4-16 Ohm, Kopfhörerausgang über Klinkenbuchse 6,3 mm; 3 Eingänge: 2× DIN 5-pol., 1× Chinch L/R; Overloadanzeige; max. Netzstromaufnahme 320 Watt bei Nennleistung

Ausgangsleistung, "garantierte Mindestwerte":

  • 2 x 60 Watt Sinus-Dauertonleistung an 4Ω
  • 2 x 45 Watt Sinus-Dauertonleistung an 8Ω
  • 2 x 30 Watt Sinus-Dauertonleistung an 16Ω
  • 2 x 90 Watt  Musikleistung an 4Ω
Net weight (2.2 lb = 1 kg) 8.9 kg / 19 lb 9.7 oz (19.604 lb)
Price in first year of sale 800.00 SFr
External source of data Erb
Source of data Katalog RFP 1974 / Radiokatalog Band 2, Ernst Erb
Mentioned in Funk-Technik (FT) (Heft 15/1973)
Literature/Schematics (1) - - Manufacturers Literature (Bedienungsanleitung)


All listed radios etc. from Studer GmbH, Willi (ReVox); Löffingen
Here you find 81 models, 61 with images and 28 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
