Synthesizer-FM-Tuner A726

Studer-Revox; Schweiz

  • Year
  • 1975 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 135241

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • FM Broadcast Band Only
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Synthesizer-FM-Tuner A726 - Studer-Revox; Schweiz
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 445 x 155 x 335 mm / 17.5 x 6.1 x 13.2 inch
  • Notes
  • Synthesizer-FM-Tuner A726.
  • Source of data
  • - - Data from my own collection
