Signal Generator 1230

Superior Instruments Co.; New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1960 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 226904

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 115 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Signal Generator 1230 - Superior Instruments Co.; New
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 14 x 6 x 11 inch / 356 x 152 x 279 mm
  • Notes

  • Frequency bands:
    0.1 - 0.3 / 0.3 - 0,85 / 0.8 - 3 / 3 - 11 / 10 - 30 / 20 - 65 / 30 - 100 MHz;
    Modulation;
    Audio frequencies. 200 / 400 / 1000 / 5000 / 7500 Hz.

  • Author
  • Model page created by Aglef Tröger. See "Data change" for further contributors.
