Tube Tester TV-11

Tube Tester TV-11; Superior Instruments (ID = 104837) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104838) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104839) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104840) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104841) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104842) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104843) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104844) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104845) Equipment

Tube Tester TV-11; Superior Instruments (ID = 104846) Equipment
Tube Tester TV-11; Superior Instruments (ID = 541828) Equipment Tube Tester TV-11; Superior Instruments (ID = 541829) Equipment
Tube Tester TV-11; Superior Instruments (ID = 541830) Equipment Tube Tester TV-11; Superior Instruments (ID = 104848) Equipment
Tube Tester TV-11; Superior Instruments (ID = 543851) Equipment Tube Tester TV-11; Superior Instruments (ID = 756687) Equipment
Tube Tester TV-11; Superior Instruments (ID = 1103943) Equipment Tube Tester TV-11; Superior Instruments (ID = 1103944) Equipment
Tube Tester TV-11; Superior Instruments (ID = 1738417) Equipment Tube Tester TV-11; Superior Instruments (ID = 1738419) Equipment
Use red slider bar for more.
Tube Tester TV-11; Superior Instruments (ID = 541828) Equipment
Superior Instruments: Tube Tester TV-11 [Equipment] ID = 541828 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tube Tester TV-11, Superior Instruments Co.; New York (NY):
1951 factory made model

Country:  United States of America (USA)
Manufacturer / Brand:  Superior Instruments Co.; New York (NY)
Year: 1951 Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Tube Tester TV-11 - Superior Instruments Co.; New
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 350 x 155 x 311 mm / 13.8 x 6.1 x 12.2 inch
Notes

11 valve holders, one 5mA instrument, manual voltage adjustment, built-in condenser tester and neon lamp NE-2. Superior TV-11 is basic emmision tester wich conects every tube as diode, merit of emmision is done in AC conditions with positioning of load reostat to apropriate value. Main goal of discarding bad tubes from good ones is well achived and testing sweep tetrodes or power audio triodes is no problem for this small tester. Main transformer is autotransforming type and there is no insulation between testing circuit and power line. So there is posibility that chassis may become "hot", use of mains separating transformer is highly recomended and could be installed inside of the tester.

Note:  It is reported that the diode shown on the schematic is drawn backwards.

Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
Source of data -- Collector info (Sammler)

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
