TU-133M

Supersonic (Chassay Bros), Bulawayo, SR

Data
Forum
Pictures
Collections

  • Year
  • 1966 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 243576

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast plus more than 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: TU-133M - Supersonic Chassay Bros,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 307 x 295 x 95 mm / 12.1 x 11.6 x 3.7 inch
  • Notes

  • Wavebands:
    BC: 550 - 1600 kHz,
    SW1: 49 - 120 m,
    SW2: 25 - 41 m,
    SW3: 11 - 49 m.

    Tuning and Fine Tuning.

    Output to be connected to TRCS 133M.



  • Net weight (2.2 lb = 1 kg)
  • 3.5 kg / 7 lb 11.3 oz (7.709 lb)
  • Author
  • Model page created by J. Virgilio Santos. See "Data change" for further contributors.
