8P18 Ch= 673-1

8P18 Ch= 673-1; Sylvania Hygrade, (ID = 147432) Radio
8P18 Ch= 673-1; Sylvania Hygrade, (ID = 2321373) Radio
Use red slider bar for more.
8P18 Ch= 673-1; Sylvania Hygrade, (ID = 2321373) Radio
Sylvania Hygrade,: 8P18 Ch= 673-1 [Radio] ID = 2321373 558x900
Select picture or schematic to display from thumbnails on the right and click for download.
For model 8P18 Ch= 673-1, Sylvania (Hygrade, GTE, Nilco); Emporium (PA):
Ebay-Verk.: ameliechen2002, ArtNr.: 113333740681

Country:  United States of America (USA)
Manufacturer / Brand:  Sylvania (Hygrade, GTE, Nilco); Emporium (PA)
Year: 1960 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2N194 2N94 2N94 SYL1583 SYL1858 SYL1858 2N1059 2N1059
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm
Power out
from Radiomuseum.org Model: 8P18 Ch= 673-1 - Sylvania Hygrade, GTE, Nilco;
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Circuit diagram reference Beitman Radio Diagrams Vol. 21, 1961

Model page created by Egon Penker. See "Data change" for further contributors.



All listed radios etc. from Sylvania (Hygrade, GTE, Nilco); Emporium (PA)
Here you find 894 models, 412 with images and 756 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
