• Year
  • 2008 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 188680

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 6 x 1,5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Frequency Counter FC-2700 - Taiyuan No.2 太原无线电二厂
  • Dimensions (WHD)
  • 11 x 8.3 x 3.5 inch / 279 x 211 x 89 mm
  • Notes
  • Ranges:
    2.7GHz: 100MHz to 2700 MHz
    100MHz: 10 MHz to 100 MHz
    10MHz: 10 Hz to 10 MHz.
    Resolution: 0.1 Hz
    Accuracy: 2 ppm +1 count
    TCXO (temperature compensated crystal oscillator) time base
    Input impedance: 1MΩ and 50Ω switchable.
    8 digit LED display.
  • Net weight (2.2 lb = 1 kg)
  • 1.2 kg / 2 lb 10.3 oz (2.643 lb)
  • Price in first year of sale
  • 250.00 EUR
