• Country
• Norway

• Manufacturer / Brand
• Tandberg Radio; Oslo

• Year
• 1968–1975

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 71523

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 20

• Semiconductors

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 16 cm = 6.3 inch

• Power out
• 14 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Baandopptaker TB15 - Tandberg Radio; Oslo

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 390 x 300 x 170 mm / 15.4 x 11.8 x 6.7 inch

• Notes

• Zweispur-Mono-Gerät; Preis in Deutschland ca. 985 DM.
  Ausführliche Service-Unterlagen bei TB14-21.

• Net weight (2.2 lb = 1 kg)
• 8.7 kg / 19 lb 2.6 oz (19.163 lb)

• Price in first year of sale
• 1,145.00 NKr.

• Author
• Model page created by Ernst Rykkje. See "Data change" for further contributors.
