A-4010SL

TEAC; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1970 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 268219
    • Brand: Tascam

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 117 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: A-4010SL - TEAC; Tokyo
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 17.5 x 17.5 x 10 inch / 445 x 445 x 254 mm
  • Notes

  • TEAC A-4010SL is a Reel to Reel Tape Deck/ Recorder made in Japan. This model has 7 1/2 IPS and 3 3/4 IPS speeds.

    Specifications

    Track system: auto reverse, 4-track, 2-channel, stereo system
    Heads: 2 x playback, 1 x erase, 1 x record
    Motor: 2 x reel, 1 x capstan
    Reel size: up to 7 inch reel
    Tape speeds: 3 3⁄4  7 1⁄2 ips
    Wow and flutter: 0.12% (7 1⁄2 ips)
    Frequency response: 30Hz to 20kHz (7 1⁄2 ips)
    Signal to Noise Ratio: 50dB
    Crosstalk: 40dB
    Input: 80mV (line), 0.25mV (mic)
    Output: 0.5V (line)
    Dimensions: 17 1/2 x 17 1/2 x 10 inches
    Weight: 47 lbs without packing

  • Net weight (2.2 lb = 1 kg)
  • 47 lb (47 lb 0 oz) / 21.338 kg
  • Author
  • Model page created by Noemi Erb. See "Data change" for further contributors.
