Stereo Cassette Deck A-770

Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 2126737) R-Player Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 2126734) R-Player
Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 2126735) R-Player Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 2126736) R-Player
Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 651855) R-Player Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 2126738) R-Player
Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 2126739) R-Player Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 2126740) R-Player
Use red slider bar for more.
Stereo Cassette Deck A-770; TEAC; Tokyo (ID = 2126737) R-Player
TEAC; Tokyo: Stereo Cassette Deck A-770 [R-Player] ID = 2126737 1400x768
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Cassette Deck A-770, TEAC; Tokyo

Country:  Japan
Manufacturer / Brand:  TEAC; Tokyo
Brand

Tascam
Year: 1980 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player; Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / see remarks: 100-240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Cassette Deck A-770 - TEAC; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 431 x 126 x 302 mm / 17 x 5 x 11.9 inch
Notes

Frontloading 3 Head Stereo Cassette Deck with Dolby B and Metal Tape Capability.
2-Position Equalization Selector, 3-Digit Digital Counter, Analog Needle Meters.
Wired Remote Control.

Type: 3-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.76 cm/s
Heads: 1 x combination record/playback, 1 x erase
Motor: 1 x reel, 1 x capstan
Tape Type: Type I (Fe), Type II (CrO2), Type IV (Metal)
Noise Reduction: Dolby B
Signal to Noise Ratio: 55dB  (w/ Dolby B)
Wow and Flutter: 0.2%
Total Harmonic Distortion: 2.2%
Input: 275mV (line), 0.35mV (mic)
Output: 0.435V (line)
Power requirements:

  • 50/60 Hz, 100; 117; 220; 240V AC (General Export model)
  • 60 Hz, 117V AC (USA / Canada)
  • 50 Hz, 220V AC (Europe)
  • 50 Hz, 240V AC (UK / Australia)
Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)

Model page created by Franz Scharner. See "Data change" for further contributors.
