Stereo Tape Deck A-2500

TEAC; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1971 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 313289
    • Brand: Tascam

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder; Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 100; 117; 200; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Stereo Tape Deck A-2500 - TEAC; Tokyo
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 440 x 383 x 203 mm / 17.3 x 15.1 x 8 inch
  • Notes

  • A 4 track 2 channel stereo tape recorder, 2 speeds (7½ and 3¾ ips), 2 motors, 3 heads, maximum reel size 7 inches. Record Pause control, Bias Current Control Switch, Monitoring Facility, Built-in Mic-Line mixer, Automatic Reverse.

    Specification
    Wow & Flutter:           7½ ips 0.12%, 3¾ ips 0.15%
    Frequency Response: 7½ ips  30 - 20,000Hz (50 - 10,000Hz ±3 dB)
                                     3¾ ips  30 - 15,000Hz (50 - 10,000Hz ±3 dB)
    S/N Ratio:                  50dB
    Inputs:                       Mic: 10kΩ, -70dB (0.3mV min.)
                                     Line: 0.1V min., Impedance 100kΩ
    Outputs:                    Approx 0.3V (-10dB)
    Headphones:             8Ω (low impedance)

  • Net weight (2.2 lb = 1 kg)
  • 17 kg / 37 lb 7.1 oz (37.445 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Instruction manual Teac A-2500 Stereo Tape Deck)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
