Soundman AFX-12 Micro-Stereo

Soundman AFX-12 Micro-Stereo; TEC Dieter Beer; (ID = 559852) Radio Soundman AFX-12 Micro-Stereo; TEC Dieter Beer; (ID = 549109) Radio
Soundman AFX-12 Micro-Stereo; TEC Dieter Beer; (ID = 706177) Radio
Use red slider bar for more.
Soundman AFX-12 Micro-Stereo; TEC Dieter Beer; (ID = 559852) Radio
TEC Dieter Beer;: Soundman AFX-12 Micro-Stereo [Radio] ID = 559852 750x448
Select picture or schematic to display from thumbnails on the right and click for download.
For model Soundman AFX-12 Micro-Stereo, TEC Dieter Beer; Wiesbaden:
Original prospekt in 1982.

Country:  Germany
Manufacturer / Brand:  TEC Dieter Beer; Wiesbaden
Year: 1982 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 2:
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 × 1.5 Volt
Loudspeaker 2 Loudspeakers
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Soundman AFX-12 Micro-Stereo - TEC Dieter Beer; Wiesbaden
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 75 x 42 mm / 9.4 x 3 x 1.7 inch
Notes AM/FM-Stereo-Transistorradio mit LED-Anzeige,
Klang- und Balance-Regler, UKW Mono/Stereo-Schalter, Kopfhörerbuchse, Teleskop-Antenne. Eingebaute Ferrit-Antenne. Tragegurt. Gehäusefarbe Goldchampagner.
Anschlussbuchse für externes Netzteil. 2 Transistoren im UKW-Eingang, 4 ICs, 2 Dioden, 1 LED, Frequenzbereich: UKW 87,5-108 MHz, MW 525-1605 kHz. FTZ Nr. 11/588, S.Nr. 01/051
Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
