For model Service-Oszillograf EO1/71a, Technisch-Physikalische Werkstätten, (TPW), VEB; Thalheim (Ostd.)

Country:  Germany
Manufacturer / Brand:  Technisch-Physikalische Werkstätten, (TPW), VEB; Thalheim (Ostd.)
alternative name

TPW
Year: 1960 ?? Category: Service- or Lab Equipment
Valves / Tubes 8: ECC85 ECC85 ECC85 ECC85 ECC85 ECC85 EZ80 B7S1 StR90/40 StR90/40
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Service-Oszillograf EO1/71a - Technisch-Physikalische Werkst
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 170 x 210 x 280 mm / 6.7 x 8.3 x 11 inch
Notes Service Ozillograf. Mechanischer Aufbau wie EO1/71, nur geringfügige Veränderungen elektrisch.
Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Collectors' prices
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Anders; Schaltungssammlung der Meßgeräte; DDR 1979
Documents about this model
  Bedienunsanleitung für Oszillograf EO71a von RTF 749 KB

Model page created by Jörg Kulbe. See "Data change" for further contributors.
