TechniLine 32; TechniSat Digital (ID = 1230096) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  TechniSat Digital GmbH, Daun ("neu RFT")
Year: 2001 Category: Television Receiver (TV) or Monitor
Main principle PLL, Phase-locked loop
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 230 Volt
Loudspeaker 2 Loudspeakers
Power out 10 W (unknown quality)
from Radiomuseum.org Model: TechniLine 32 - TechniSat Digital GmbH, Daun "
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 915 x 555 x 570 mm / 36 x 21.9 x 22.4 inch
Notes Der Empfänger Techniline 32 hat eine Real Flat- Bildröhre 82 cm, Format 16 zu 9 und arbeitet in 100 Hz- Technik. Das Gerät empfängt die Kanäle E02 - E12, E21 - E69 und S01 - S40 nach CCIR, PAL/ Secam, speicherbar auf 99 Programmplätzen. Die Tonsignalverarbeitung umfaßt die Standards BG FM- Stereo, NICAM, DK, sowie Mono I und LL. Videotextspeicher für 250 Seiten, Formatumschaltung, Kindersicherung und 2 Scartbuchsen sind eingebaut. Basis ist das Chassis "Professional 8500" von Orion
Net weight (2.2 lb = 1 kg) 52.5 kg / 115 lb 10.2 oz (115.639 lb)
Source of data -- Original-techn. papers.

Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.
