Gloria 4 RP 1524

Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613914) Radio Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613909) Radio
Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613906) Radio Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613910) Radio
Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613911) Radio Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613912) Radio
Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613915) Radio Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613916) Radio
Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 1114844) Radio Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 1114845) Radio
Use red slider bar for more.
Gloria 4 RP 1524; Tehnoton S.A.; Iasi (ID = 613914) Radio
Tehnoton S.A.; Iasi: Gloria 4 RP 1524 [Radio] ID = 613914 734x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gloria 4 RP 1524, Tehnoton S.A.; Iasi:
Sammlung

Country:  Romania
Manufacturer / Brand:  Tehnoton S.A.; Iasi
Year: 1985 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Gloria 4 RP 1524 - Tehnoton S.A.; Iasi
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 310 x 200 x 85 mm / 12.2 x 7.9 x 3.3 inch
Notes Gloria 4, Wellen: US1 = 5,9 bis 9,3 MHz, US2 11,5 bis 18,5 MHz, UUS 65 bis 73 MHz, UMS 525 bis 1600 kHz, UL 150 bis 255 kHz, Bass und Höhenregler, Skalenbeleuchtung, Teleskopantenne, Zusatslautsprecherbuchse, DIN-Tonbandbuchse.
Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Collectors' prices

Model page created by Karlheinz Fischer. See "Data change" for further contributors.
