Type CA Plug-In-Unit C-A

Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 598155) Equipment

Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 598157) Equipment
Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 2259261) Equipment Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 2259262) Equipment
Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 2289385) Equipment Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 167467) Equipment
Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 167468) Equipment Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 167469) Equipment
Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 167706) Equipment Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 167707) Equipment
Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 167708) Equipment Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 596053) Equipment
Use red slider bar for more.
Type CA Plug-In-Unit C-A; Tektronix; Portland, (ID = 2259261) Equipment
Tektronix; Portland,: Type CA Plug-In-Unit C-A [Equipment] ID = 2259261 1200x975
Select picture or schematic to display from thumbnails on the right and click for download.
For model Type CA Plug-In-Unit C-A, Tektronix; Portland, OR

Country:  United States of America (USA)
Manufacturer / Brand:  Tektronix; Portland, OR
Year: 1959–1964 Category: Service- or Lab Equipment
Valves / Tubes 15: 6AK5 6AK5 6AL5 6AU6 6AU6 6AU6 6AU6 12AT7 12AT7 12AT7 12AT7 12AU6 12AU6 12AU6 12AU6
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Type CA Plug-In-Unit C-A - Tektronix; Portland, OR
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 150 x 175 x 270 mm / 5.9 x 6.9 x 10.6 inch
Notes High-speed dual channel vertical amplifier. DC to 24 MHz bandpass when used on fast-risetime mainframes, as the 545 or the 585.
Derived from 53/54C plug-in amplifier with the addition of algebraic sum mode, 'Add algebraically', hence C-A and not simply C.
A 53/54CA type probably never appeared. A February 1959 abridged catalog lists the 53/54C type, while the July edition of the same year lists the C-A, letter type plug-in.
Net weight (2.2 lb = 1 kg) 1.750 kg / 3 lb 13.7 oz (3.855 lb)
Price in first year of sale 250.00 $
Source of data -- Original-techn. papers.
