Oscilloscope 310
Tektronix; Portland, OR
- Country
- United States of America (USA)
- Manufacturer / Brand
- Tektronix; Portland, OR
- Year
- 1955
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 84358
Bild aus Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 31
- Power type and voltage
- Alternating Current supply (AC) / 117/234 Volt
- Material
- Metal case
- from Radiomuseum.org
- Model: Oscilloscope 310 - Tektronix; Portland, OR
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 6.75 x 10 x 17 inch / 171 x 254 x 432 mm
- Notes
- some tubes are multiply used, CRT 3WP2.
- Net weight (2.2 lb = 1 kg)
- 10.7 kg / 23 lb 9.1 oz (23.568 lb)
- Price in first year of sale
- 595.00 $
- Source of data
- -- Original-techn. papers.
- Literature/Schematics (1)
- Electronics, May 1955
| Tektronix 310: One of the early ads for 310 portable oscilloscope from Electronics, May 1955. | 348 KB |
- Documents regarding this model
- Author
- Model page created by Felix Schaffhauser. See "Data change" for further contributors.
