Oscilloscope 543B

Tektronix; Portland, OR

  • Year
  • 1964
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 144645

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 45
  • Number of Transistors
  • 11
  • Semiconductors
  • Main principle
  • none
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 108; 115; 122; 216; 230; 244 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Oscilloscope 543B - Tektronix; Portland, OR
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • CRT: T5470-31-2, DC coupled, 10 kV, 6 x 10 cm, Type 31 phosphor.
    Horizontal: 0.1µs to 5s in 24 steps.
    Vertical: 0.1, 1 or 10 V/cm; DC to 500 kHz.
  • Net weight (2.2 lb = 1 kg)
  • 36.7 kg / 80 lb 13.4 oz (80.837 lb)
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Pius Steiner. See "Data change" for further contributors.
