For model 195 (R.M.A. No. 347), Tele-Tone Radio Corp., Tele-Tone Co. Inc.; New York (NY):
Greg Mercurio

Country:  United States of America (USA)
Manufacturer / Brand:  Tele-Tone Radio Corp., Tele-Tone Co. Inc.; New York (NY)
alternative name

Teletone
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 12BE6 12SQ7 50L6GT 35Z5GT
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: 195 - Tele-Tone Radio Corp., Tele-
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 8.5 x 6 x 4 inch / 216 x 152 x 102 mm
Notes This originally inexpensive Tele-Tone (not Teletone) model 195 has a R.M.A. number of 347. RMA stands for "Return Material Authorization". Several models have the same RMA number ... This radio has a very nice architectural design. The plastic can have different colors, it can also be swirled tan and white. This plastic is quite thin and brittle making for easy tube burn to the top and, of course breakage. It has a 11 ft. long wire antenna.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Source of data Collector's Guide to Antique Radios 4. Edition
Mentioned in Evolution of the Radio (Volume 1) (vol.2)
Literature/Schematics (1) - - Data from my own collection

Model page created by Robert Higgins. See "Data change" for further contributors.
