• Country
• Norway

• Manufacturer / Brand
• Telefunken El.-Gen.Aksjeselskap

• Year
• 1946

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 125348

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH35 EBF32 EF39 EL33 EM34 U50

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 120; 150; 230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Safir 3 - Telefunken El.-Gen.

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 540 x 310 x 250 mm / 21.3 x 12.2 x 9.8 inch

• Price in first year of sale
• 480.00 NKr

• Mentioned in
• The Norwegian Historical Radio Society

• Author
• Model page created by Ernst Rykkje. See "Data change" for further contributors.
