• Country
• Switzerland

• Manufacturer / Brand
• Télévox (TELEVOX SA); Neuchâtel

• Year
• 1923–1926

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 13663

• Number of Tubes
• 6

• Valves / Tubes

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown); 3 Special; 2 AF stage(s)

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 4 & 80 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case, TUBES VISIBLE.

• from Radiomuseum.org
• Model: Semper-Radiola - Télévox TELEVOX SA; Neuchâtel

• Dimensions (WHD)
• 820 x 300 x 250 mm / 32.3 x 11.8 x 9.8 inch

• Notes
• 3fach-Spulenkoppler;grösstes Mod.Televox [332405-87B]; Mai 1924 nicht "neu", Spitzliröhren

• Net weight (2.2 lb = 1 kg)
• 8.1 kg / 17 lb 13.5 oz (17.841 lb)

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Other Models

• Here you find 26 models, 18 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
