Satellite Signal Meter - Sat Finder

Satellite Signal Meter - Sat Finder ; Telmal Sp. z o.o.; (ID = 1300674) Equipment Satellite Signal Meter - Sat Finder ; Telmal Sp. z o.o.; (ID = 1303622) Equipment
Use red slider bar for more.
Satellite Signal Meter - Sat Finder ; Telmal Sp. z o.o.; (ID = 1300674) Equipment
Telmal Sp. z o.o.;: Satellite Signal Meter - Sat Finder [Equipment] ID = 1300674 933x570
Select picture or schematic to display from thumbnails on the right and click for download.
For model Satellite Signal Meter - Sat Finder, Telmal Sp. z o.o.; Gdansk

Country:  Poland
Manufacturer / Brand:  Telmal Sp. z o.o.; Gdansk
Year: 1999 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / 12 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Satellite Signal Meter - Sat Finder - Telmal Sp. z o.o.; Gdansk
Material Various materials
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 90 x 75 x 35 mm / 3.5 x 3 x 1.4 inch
Notes Frequency Range 950 MHz to 2150 MHz; F type IN/OUT connectors; Voltage Supply applied at OUT connector; Maximum Gain 11 dB; Input Level Range 52 to 60 dB; IN/OUT Impedance 75 ohms; connected between satellite dish and receiver permit to find the satellite without having to use TV.
Net weight (2.2 lb = 1 kg) 0.150 kg / 0 lb 5.3 oz (0.33 lb)
Source of data -- Original prospect or advert

Model page created by Emilio Focosi. See "Data change" for further contributors.
