VHF transceiver P-254-M

Teltronic, S.A. Zaragoza

  • Year
  • 1955 ??
  • Category
  • Commercial Transmitter & Receiver (TRX not Amateur)
  • Radiomuseum.org ID
  • 217153

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Transceiver; ZF/IF 10700/455 kHz; 1 AF stage(s)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Powered by external power supply or a main unit. / 13,8 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
  • Power out
  • 2 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: VHF transceiver P-254-M - Teltronic, S.A. Zaragoza
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 165 x 65 x 235 mm / 6.5 x 2.6 x 9.3 inch
  • Notes
  • 4 canales a cristal de cuarzo, entre 60-88 MHz. 20 W RF out
  • Net weight (2.2 lb = 1 kg)
  • 1.8 kg / 3 lb 15.4 oz (3.965 lb)
  • Source of data
  • - - Data from my own collection
